May/June
2010
Reload
to see the latest news
All news content copyright Michael J. Fuller, unless
otherwise noted |
| | >>Click here for Le Mans 2010 coverage<< | | 6.20.10
>>So
with Le Mans 2010 having come and gone we're still no closer to having
definitive 2011 regulations. In the mean time we understand there
is active discussion amongst the manufacturers (the teams are out of
the loop) and the ACO. The primary topic of concern are the
details of the 2011 grandfathering with the manufacturers and teams
waiting with baited breath. One who wishes to remain anonymous
recently stated to us in an email, "This is the ACO's to spoil in my
opinion. And if they make the restrictions too onerous for
current cars many teams may stay at home or do something else next
year."
Interestingly we're also hearing that the ACO is deathly afraid
of this possibility, though the ball's in their court.
Ironically
this could end up being a windfall for the American Le Mans Series.
While the ALMS hasn't stated anything in regards to 2011, it is
pretty well assumed they will adopt less a restrictive interpretation
of the ACO's 2011 regulations, slowly integrating the full regulations
across a longer time period.
Let's hope the ALMS takes advantage of this potential opportunity.
|
| 6.16.10
>>We've
finally sat down and had a read through of the Version 4 draft of the
2011 regulations. In this draft it clearly states that yes, for
2011, you will be able to run your current LMP1 or LMP2 with only one
modification, namely the great-honking-fin. This is all covered
under Article 19. The ACO has laid out slightly different
regulations for LMP1 and LMP2 and we'll break them down.
At this
time the ACO has not called out the restrictor or boost reductions that
2010 LMP1s will have to entertain while also indicating that a
performance advantage (slight) will be given to new 2011 rules
compliant LMP1s. The ACO also states that the only
modifications that will be allowed on the old-rules engines, "...will
be those necessary for the use of new restrictors in order to maintain
the efficiency of the engine." These modifications will need to
be documented and signed off by the ACO. The ACO also states that
the engine builder will need to maintain an example of their 2010 power
plant such that it can be compared should any questions arise.
Fuel capacities of 2010 LMP1s will also need to be brought in
line with LMP1 2011. The ACO reserves the right to alter LMP1
performance relative to its competitors through adjustments in weight,
inlet restrictor, and fuel capacity as needed.
For LMP2 the ACO
will equalize performance through adjustments in weight, fuel capacity,
inlet restrictor, or whatever other method deemed necessary by the ACO.
At this time the ACO hasn't stated what the starting point will
be for any of the parameters. The ACO explicitly states that
should a car shown performance above any of the others they will take
immediate steps to reduce that car's performance by the next event.
The
ACO has also defined eligibility requirements of current LMP2s for
2011, 2012, and 2013 that currently do not meet the 2011 price cap.
LMP2s homologated before 3/31/2010 are eligible for 2011-2013 as
long as:
>only a single variation of bodywork is eligible during the season
>the
car's performance will be evaluated relative to its competitors and
subsequently adjusted (after taking part in an ACO organized pre-season
test)
>the only allowable modification is the fitment of the
obligatory great-honking-fin and the installation of a production based
engine
> the chassis manufacturer is allowed to build new duplicate chassis as long as they meet all the above requirements
Naturally these aren't official until the ACO actually finalizes the regulations... | |  5.20.10
>>We've
been waiting a while to be able to use this image, so it's made the
rounds by now. This shot appeared after the Paul Ricard Le Mans
Series race and is interesting if simply because we can see the VGs on
the under side of the R15's front diffuser.
| |  5.15.10
>>Radical
regulation changes are looming for next year and little has been
officially said since the initial announcements last year, so we went
digging to see what was being discussed behind the scenes and were a
bit surprised by the responses.
>>Yes,
"honking great fins," as one put it, will unfortunately be adorning all
the cars next year as the ACO's solution for reducing
sudden high-speed yaw-induced blow overs. We understand this
concept was developed 18 months ago and presented by Porsche to the FIA
as a possible solution.
We've also been told that when combined with the domed 20 mm skid
(proposed by Wirth Research and adopted at the beginning of the 2009 seasons)
the fin shows to be pretty effective. But ironically we're told
that the fin itself generates a substantial over turning moment.
But this over turning moment is offset by the fin's ability to
kill the lift created by the leading side rear wheel arch when the car
is suddenly yawed 90°.
But more than one aerodynamicists has indicated that the fin also
disrupt airflow to the rear wing in normal yaw moments (cornering, 0-5°),
leading one to wonder if the solution was throughly thought out and
sorted beyond a day or two in a full scale yaw tunnel? We're sure
it has been, but we still would have hoped that the ACO would have
commissioned an independent aerodynamics research study (similar to the
Piper study that helped establish the 2004 LMP regulations related to
yaw safety) to properly
investigate the problem instead relying on what appears to be a
grab bag of solutions put forth by various groups working separately.
>>Beginning
next year, the ACO will be radically changing the engine regulations
for LMP1 and LMP2. As we understand it at the moment, the intention is that 2011 LMP1s will be powered
by either normally aspirated engines up to 3.4 liters and 8 cylinders, turbo engines up to 2.0 liters and 6 cylinders, or turbo diesel engines up to 3.7 liters and 8 cylinders. The LMP2 engine landscape is changing as well and will embrace homologated normally aspirated engines up to a maximum of 5.0 liters and 8-cylinders and homologated turbos up to a maximum of 4.0 liters and 8 cylinders.
We're told the 2011 regulations have
been changed at least three times this year alone though can hope that
some permanence will be reached, and soon (we're told today, 5.17.10,
Le Mans at the earliest). Does it need reminding that most of the
world is
still dealing with the recession? But regardless,
pretty big changes are on the horizon.
With the
last large set of regulation changes (2004), the ACO allowed the grand
fathering of the existing cars, allowing manufacturers and competitors
to ease into the new regulations thus not obsolescing any of the
existing cars with the regulation change. It worked rather well
and the LMP900 and LMP675s continued on with increased weight and
reduced diameter engine inlet restrictors allowing them to race along
side the LMP1s and LMP2s through 2006.
But we've been told that
with the switch to 2011 engine rules the ACO has no interest in grand
fathering existing engines. Therefore it would appear that the
onus will fall upon the independents to immediately produce engines
that fit into the new framework and new chassis' optimized to the new
regulations (yes, we're aware this has been looming for a couple of
years now, but the expectation was always for an overlap period).
With that as the only option, we understand that inquiries have
been made to the ACO, but the general consensus is that grand fathering
is off the table. And there seems to be little chance in this
changing short of convincing the ACO that moving forward will
decimate the field for the 2011 24 Hours of Le Mans; Le Mans Series,
and especially the ALMS, be damned.
>>Further
inquiry about the engine regulation changes revealed particular
dissatisfaction with the direction in LMP2, with special discontent
being ladled over the mirage of decreased cost with the utilization of
production based engines for 2011 and beyond. Since most
production engines are simply unsuitable as racing engines, the ACO is
allowing the substitution of most of the engine internals for bespoke
racing replacements. At their September 13, 2008 press conference
the ACO espoused the desire that the 2011 regulations also take into
consideration cost containment for the LMP2 category by switching to
production based engines. But let's consider the expense of
taking a 200 kg production based engine and paring it down to 150 kgs
or less. Added to that the veritable free-for-all regarding the
engine's internal design, and the regulation changes hardly seem to
create a solid foundation for cost containment. In addition to
this, the ACO will also be implementing a price cap of €75000
($95243) per engine including ECU, wiring harness, and track
support engineer. That's the cap for 2011, but the cap is lowered
in proceeding years, putting engine builders in the difficult position
of racing in a competitive racing series with designed-in
shrinking profitability. |
|
 |
